Bam303G Medical Surgical 3 Functions Manual Orthopedics Traction Patient Nursing Bed with Double Arm

Customization: Available
Material: Metal
Type: Orthopedic Bed

Product Description

Medical Surgical Orthopedics Traction Nursing Bed

BAM303G Medical Surgical 3 Functions Manual Orthopedics Traction Patient Nursing Bed

Basic Specifications

Model NO.
BAM303G
Function
Three-function
Folded
Unfolded
Certification
CE
Head/Tail Plates
ABS Material
Sleeping Bed Size
1960*830mm
Max Loading
250kgs
Dimensions
2130*990*490mm

Key Features

  • Four-part bed plate made of high-quality cold-rolled steel with electrostatic spraying.
  • ABS head and tail plates with locking device, usable as CPR plates for emergencies.
  • Three-crank system for adjusting backrest and bilateral knee lift functions.
  • Stainless steel double-arm traction rack for cervical or multi-part orthopedic traction.
  • Removable orthopedic traction racks located conveniently under head and foot ends.
  • 6-segment aluminum alloy side railings to ensure patient safety.
  • 125mm diameter noiseless casters featuring independent braking systems.
  • Optimized for treatment, traction, and rehabilitation of orthopedic patients.

Product Parameters

Technical Specification Detail
ModelBAM303G
Overall Length2130mm
Overall Width990mm
Bed Base Height490mm
Backrest Max Angle0-75°
Knee Section (Left) Up0-40°
Knee Section (Right) Up0-40°
Loading Capacity250kg

Quality Control & Production

Production Process 1
Production Process 2

Frequently Asked Questions

What are the primary functions of the BAM303G bed?
The bed features three manual crank functions, allowing for the adjustment of the backrest angle (0-75°) and independent lifting of the left and right knee sections (0-40°).
What makes the traction rack special?
It is equipped with a stainless steel double-arm traction rack. This versatile rack can be used for cervical traction, double-arm traction, or other localized orthopedic treatments.
Can the head and tail plates be removed for emergencies?
Yes, the ABS head and tail plates are equipped with a quick-locking device, allowing them to be detached rapidly to serve as cardiopulmonary resuscitation (CPR) plates during clinical first aid.
What is the weight capacity and durability of the bed?
The bed is constructed from high-quality cold-rolled steel with an electrostatic spray coating, providing a robust loading capacity of up to 250kg.
Are there any safety features to prevent patient falls?
Yes, the bed includes 6-segment aluminum alloy side railings that provide secure protection and 125mm noiseless casters with independent brakes for stable positioning.
What are the optional accessories available?
Optional additions include a mattress, weighing system, extended bed frame, IV pole, X-ray bed board, and oxygen cylinder holder.
